Lucent Technologies DDM-2000 OC-12 User Manual

xxii Issue 1 December 1997
Contents
9 Maintenance Description
■ Overview 9-1
Three-Tiered Operations 9-1
■ Single-Ended Maintenance Philosophy 9-4
Multi-Vendor OI 9-6
■ In-service (IS) Upgrades 9-8
Software Upgrades 9-8
■ DDM-2000 OC-3 and OC-12 Software Compatibility 9-9
■ Maintenance Signaling 9-10
■ Fault Detection, Isolation, and Reporting 9-16
Detection 9-16
Isolation 9-16
Reporting 9-16
■ Protection Switching 9-17
Automatic Line Protection 9-17
Status of ACTIVE LED on OLIUs 9-17
APS Initiation Criteria 9-18
Equipment Protection 9-20
Synchronization Reference Protection 9-20
Path Protection Switching (Path Switched Rings) 9-21
Path Protection Scheme 9-22
Dual Ring Interworking (DRI) Path Protection
Scheme 9-24
OC-3/OC-12 Path Switched Ring (0x1) 9-26
Status of ACTIVE LED on Rings 9-26
■ Loopbacks 9-26
■ Tests 9-27
Transmission Tests 9-27
Operations Interface Tests 9-27
■ Performance Monitoring (PM) 9-27
DS3 Performance Monitoring (PM) 9-29
DS3 Path PM 9-29
P-Bit 9-29

Lucent Technologies DDM-2000 OC-12 Specifications

General

Brand	Lucent Technologies
Model	DDM-2000 OC-12
Category	Multiplexer
Language	English
