363-206-295
Technical Specifications
Issue 1 December 1997 10-33
Physical Specifications 10
OC-12 Shelf Physical Characteristics 10
■ Dimensions: 14 in. H x 21.25 in. W x 12 in. D (Group 1)
Dimensions: 14 in. H x 21.25 in. W x 13.25 in. D (Group 4)
■ Weight (Max.): 83 lb. (38 kg)
■ Appearance: Coordinated with other equipment in the Lucent 2000 Product
Family.
Fan Shelf Physical Characteristics 10
■ Dimensions: 4 in. H x 21.25 in. W x 9 in. D
■ Weight (Max.): 20 lb. (9 kg)
■ Appearance: Coordinated with other equipment in the Lucent 2000 Product
Family.
Network Bay and Cabinet Mounting 10
DDM-2000 OC-12 Multiplexers can be mounted in ED-8C500, ED-8C501 and
ED-8C800, ED-8C801 (seismic) network bay frames. A maximum of three
DDM-2000 OC-12 shelves may be mounted in a 7-foot bay. One OC-12 shelf and
four OC-3 shelves can be mounted in a 7-foot bay. In addition to bay mounting,
DDM-2000 OC-12 can be packaged with other equipment in 80A, 80D, and 80E
cabinets, controlled environment vaults (CEVs), or huts.
NOTE:
The mounting brackets on the DDM-2000 OC-3, OC-12, heat baffle, and
fan shelf are designed to allow for mounting in standard 23-inch wide
network bay frames and 23-inch wide EIA-type bay frames.
