363-206-295
Commands and Reports
11-4
Issue 1 December 1997
Table 11-1. DDM-2000 OC-12 Address Table
Object Entity Address Example
Entire System all all
Main slot main-{a,b,all*}-{1,2,all} main-all
TSI unit slot tsi-{1,2,all} tsi-1
Slots
Function unit slot fn-{a,b,c,d,all*}-{1,2,all} fn-all
fn-b-all
fn-d-1
Timing slot t
-{1,2,all} tg-all
Sys. control slot sysctl sysctl
Aux. control slot auxctl auxctl
OC-12 line pair all
main-{b,all}
all
main-b
Lines
OC-12 line all
main-b-{1,2,all}
all
main-b-1
OC-3 line pair all
fn-{a,b,c,d,all}
all
fn-b
OC-3 line all
fn-{a,b,c,d,all*}-{1,2,all}
all
fn-c-2
DS-3 port {a,b,c,d,all*}-{1-3,all} a-2
Ports
DS1 sync. ref. port ref-{1,2} ref-1
EC-1 port {a,b,c,d,all*}-{1-3,all} b-3
STS-1 channel
(within OC-12)
{mb,all*}-{1-12,all}
mb{1,2}-{1-12}
mb-4
mb1-4
Channels
STS-1 channel
(within OC-3)
{a,b,c,d,all*}-{1-3,all} c-1
b-3
STS-3c channel
(within OC-12)
mb-{1,4,7,10},all
mb{1,2}-{1,4,7,10,all}
mb-4
mb1-1
Main mb-{1-12,all} mb-8
STS-1
Function unit {a,b,c,d}-{1-3,all} b-1
Cross-
3STS1E port {a,b,c,d}-{1-3,all} a-2
Connections
3DS3 port {a,b,c,d}-{1-3,all} c-1
Function Unit (OLIU) {a,b,c,d}-{1-3,all} d-3
* If all is chosen as any part of an address, no subsequent address fields should be defined.
(Table continues on the following page)
