Manitowoc 18000 Service Maintenance Manual

Reference Only
18000 SERIVCE/MAINTENANCE MANUAL HYDRAULIC SYSTEM
Manitowoc Published 12-05-17, Control # 035-23 2-19
2
FIGURE 2-16
P1922
Typical 2 Places
P1930a
P2002
Inside Adapter
Frame
2
3
1
5
7
4
5
3
6
7
Item Description
1 Swing Motor (4 places)
2Swing Brake
3 Case Drain Port (typical)
4 Swing Brake Solenoid Valve
5 Electrical Plug (typical)
6 Travel Motor (4 places)
7 Travel Brake (4 places)
8 Drum 5 (Mast Hoist) Motor
9 Drum 5 Brake
10 Drum 5 Brake Solenoid Valve
Following items for Drums 1, 2, 3, 4, and 6
11 Drum Motor
12 Drum Brake (inside gear box)
13 Drum Brake Solenoid Valve
P1930a
P1995a
10
5
P2013b
983
5 13
3
11
12
Drum 6 (Luffing Hoist) Shown
Typical for:
Drum 1 (Main Hoist) - Both Ends
Drum 2 (Main Hoist) - Both Ends
Drum 3 (Whip Hoist) - Left End
Drum 4 (Boom Hoist) - Both Ends
Drum 6 (Luffing Hoist) - Left End
P2013c
18CSM1-103
