Manitowoc 18000 Service Maintenance Manual

Reference Only
Manitowoc Published 12-05-17, Control # 035-23 3-13
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
NODE 4 - Connecting Pins, Jacking, and Mast
Reference Electrical Schematic A06374 - Sheets 8, 19 and 20.
Can ID. No.
Function
Type
Description Test Voltage Packet No.
WN04-A/WN30-A 24 Volts From Node 3 to Node 2 24 Volts Nominal
WN04-C/WN30-C CANH Can High Wire Transmission N/A
WN04-D/WN30-D Ground From Node 3 to Node 2 Ground
WN04-F/WN30-F CANL Can Low Wire Transmission N/A
J3 Receptacle – Connecting Pins
43-A Ground Mast Pins Engage Solenoid Ground
43-B DO-1 Mast Pins Engage Solenoid 0 Volts Off; 24 Volts On CAN35-1-1
43-C Ground Mast Pins Disengage Solenoid Ground
43-D DO-2 Mast Pins Disengage Solenoid 0 Volts Off; 24 Volts On CAN35-1-2
43-E Ground Boom Pins Engage Solenoid Ground
43-F DO-3 Boom Pins Engage Solenoid 0 Volts Off; 24 Volts On CAN35-1-4
43-G Ground Boom Pins Disengage Solenoid Ground
43-H DO-4 Boom Pins Disengage Solenoid 0 Volts Off; 24 Volts On CAN35-1-8
43-J Ground Jumper to Node Select 3 Ground
43-M NS-3 Node Select 3 Jumper to Ground 0 Volts (With Jumper)
43-P DO-6 Cab Tilt – Up Solenoid 0 Volts Off; 24 Volts On CAN35-1-32
43-R DO-5 Cab Tilt – Down Solenoid 0 Volts Off; 24 Volts On CAN35-1-16
43-g Ground Cab Tilt – Up Solenoid Ground
43-h Ground Cab Tilt – Down Solenoid Ground
J4 Receptacle – Jacking Solenoids
44-A Ground Drum 7 Payout Solenoid Ground
44-B DO-11 Drum 7 Payout Solenoid 0 Volts Off; 24 Volts On CAN35-2-4
44-C Ground Drum 7 Haul In Solenoid Ground
44-D DO-12 Drum 7 Haul In Solenoid 0 Volts Off; 24 Volts On CAN35-2-8
44-E Ground Right Front Jack Extend Solenoid Ground
44-F DO-13 Right Front Jack Extend Solenoid 0 Volts Off; 24 Volts On CAN35-2-16
44-G Ground Right Front Jack Retract Solenoid Ground
44-H DO-14 Right Front Jack Retract Solenoid 0 Volts Off; 24 Volts On CAN35-2-32
44-J Ground Left Front Jack Extend Solenoid Ground
44-K Ground Left Front Jack Retract Solenoid Ground
44-P DO-16 Left Front Jack Extend Solenoid 0 Volts Off; 24 Volts On CAN35-2-128
44-R DO-15 Left Front Jack Retract Solenoid 0 Volts Off; 24 Volts On CAN35-2-64
44-T Ground Right Rear Jack Extend Solenoid Ground
44-U DO-19 Right Rear Jack Extend Solenoid 0 Volts Off; 24 Volts On CAN35-3-4
44-V Ground Right Rear Jack Retract Solenoid Ground
44-W DO-20 Right Rear Jack Retract Solenoid 0 Volts Off; 24 Volts On CAN35-3-8
44-X Ground Left Rear Jack Extend Solenoid Ground
44-Z DO-21 Left Rear Jack Extend Solenoid 0 Volts Off; 24 Volts On CAN35-3-16
