Manitowoc Published 12-05-17, Control # 035-23 1-17
18000 SERIVCE/MAINTENANCE MANUAL INTRODUCTION
1
Mast Butt
Item Description
1 Mast Butt Accumulator
2 Boom Hoist (Drum 4)
3 Motor Control
4 Boom Hoist Motor (Drum 4)
5 Boom Hoist Brake (Inside Gearbox)
6 Motor Speed Sensor
7 Loop Flushing Valve
8 Pawl Electrical Junction Box
9 Boom Hoist Pawl
P2007
P2008
P2009
P2013a
4
3
9
Motor Each Side of Drum
Typical All Drums
5
7
6
2
FIGURE 1-13
1
8
18CSM1-114
