INTRODUCTION 18000 SERIVCE/MAINTENANCE MANUAL
1-10
Published 12-05-17, Control # 035-23
Rear
Item Description
1 Hydraulic Fluid Cooler
2 Fuel Cooler
3 Node 9 Controller
4 Fuel Level Gauge
5 Fuel Tank Fill Cap
6 Fuel Tank
7 Hydraulic Tank Return Filters
8 Hydraulic Tank Breather
9 Access Tank Clean-Out Cover
10 Air Bleed Valves
11 Hydraulic Liquid Level Gauge
12 Hydraulic Tank
13 Liquid Level Switch
14 Hydraulic Tank Shut Off Valves (2)
15 Live Mast Straps
16 Mast Sheaves
17 Live Mast
18 Hydraulic Tank Heater
6
P1905
P1910
P1911
P1975
12
8
9
16
13
11
5
4
15
P1991
10
1
2
3
9
17
FIGURE 1-7
Past Production
7
P1925a
18CSM1-103
14
P1910
12
10
9
11
13
9
8
7
18
S/N18001082 & Newer
Prior to s/n 18001082
S/N18001082 & Newer
Prior to s/n 18001082
S/N18001082 & Newer
IMG_4746
IMG_4740
