INTRODUCTION 18000 SERIVCE/MAINTENANCE MANUAL
1-6
Published 12-05-17, Control # 035-23
Top
Item Description Item Description Item Description
1* Charge Filter (2) 9 Engine Air Cleaner (Tier 3) 17 Travel 2-Speed Solenoid Valve
2 Engine Oil Fill Tube 10 Engine Exhaust Stack (Tier 3) 18 Adapter Frame Accumulator
3 Engine 11 Whip Line Hoist Motor (Drum 3) 19 Accessory Pressure Switch
4 Engine Coolant Radiator 12 Whip Line Hoist (Drum 3) 20 Swivel
5 Mast Assist Arms 13 Engine Cover 21 Node-7 Controller
6 Live Mast 14 Swing Brake Solenoid Valve 22 Pump Inlet Manifold
7 Mast Stop 15 Swing Lock Solenoid Valve 23 Mast Hoist Motor (Drum 5)
8 Mast Butt 16 Travel Brake Solenoid Valve 24 Mast Hoist (Drum 5)
P1997
P1912a
P2000
P2003
P2002
P2004
24
19
18
Inside Adapter Frame
7
P2001
P2005
23
6
1*
9
10
12
22
13
1*
2
3
4
11
8
14
17
15
16
Inside Adapter Frame
Inside Adapter Frame
20
Inside Adapter Frame
21
5
24
FIGURE 1-3
18CSM1-103
*Cranes prior to s/n 18001082
