Manitowoc Published 12-05-17, Control # 035-23 3-11
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
NODE 3 - Drum 3 and Pressure Senders
Reference Electrical Schematic A06374 - Sheets 7, 19 and 20.
Can ID. No.
Function
Type
Description Test Voltage Packet No.
WN10-A/WN04-A 24 Volts From Node 0 to Node 4 24 Volts
WN10-C/WN04-C CANH Can High Wire Transmission N/A
WN10-D/WN04-D Ground From Node 0 to Node 4 Ground
WN10-F/WN04-F CANL Can Low Wire Transmission N/A
J3 Receptacle – Pressure Senders
33-B DO-1
Super Charge Hydraulic Pressure (Prior to
S/N 18001082)
0 Volts Off; 24 Volts On CAN33-1-1
33-C Ground Drum 2/5 Pressure Sender Ground
33-D DO-2 Drum 2/5 Pressure Sender 0 Volts Off; 24 Volts On CAN33-1-2
33-E Ground Drum 1/3 Pressure Sender Ground
33-F DO-3 Drum 1/3 Pressure Sender 0 Volts Off; 24 Volts On CAN33-1-4
33-G Ground Accessory System Pressure Sender Ground
33-H DO-4 Accessory System Pressure Sender 0 Volts Off; 24 Volts On CAN33-1-8
33-J Ground Jumper to Node Select Ground
33-L NS-2 Node Select Jumper to Ground 0 Volts (With Jumper)
33-N Ground Right Track Pressure Sender Ground
33-P DO-6 Right Track Pressure Sender 0 Volts Off; 24 Volts On CAN33-1-32
33-R DO-5 Left Track Pressure Sender 0 Volts Off; 24 Volts On CAN33-1-16
33-T DI-3
Super Charge Hydraulic Pressure (Prior to
S/N 18001082)
0 Volts Off; 24 Volts On CAN59-1-4
33-b AI-2 Drum 2/5 Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN4-4
1
33-c AI-3 Drum 1/3 Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN4-6
1
33-d AI-4 Accessory System Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN4-8
1
33-e AI-5 Right Track Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN5-2
1
33-f AI-6 Left Track Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN5-4
1
33-g Ground Left Track Pressure Sender Ground
J4 Receptacle – Drum Pump Control
34-A Ground Drum 1/3 Pump Control – Raise Ground
34-B DO-11 Drum 1/3 Pump Control – Raise See Table 3-3
for Values CAN33-2-4
34-C Ground Drum 1/3 Pump Control – Lower Ground
34-D DO-12 Drum 1/3 Pump Control – Lower See Table 3-3
for Values CAN33-2-8
34-E Ground Drum 2/5 Pump Control – Raise Ground
34-F DO-13 Drum 2/5 Pump Control – Raise See Table 3-3
for Values CAN33-2-16
34-G Ground Drum 2/5 Pump Control – Lower Ground
34-H DO-14 Drum 2/5 Pump Control – Lower See Table 3-3
for Values CAN33-2-32
34-J Ground Drum 2 Pump Control – Raise Ground
34-K Ground Drum 2 Pump Control – Lower Ground
34-L Ground Drum 1/3 (opt.) Pump Control – Raise Ground
34-M DO-17 Drum 1/3 (opt.) Pump Control – Raise See Table 3-3
for Values CAN33-3-1
34-N Ground Drum 1/3 (opt.) Pump Control – Lower Ground
