ELECTRIC SYSTEM 18000 SERIVCE/MAINTENANCE MANUAL
3-10
Published 12-05-17, Control # 035-23
P53-A Ground Setup Receiver Ground
P53-B Ground Left Console Ground
P53-C Ground Cab Ground Ground
P53-E 28 Volts Setup Receiver 28 Volts Nominal
P53-F 28 Volts Bar Graph Display 28 Volts Nominal
1
– Lower four bits are the most significant bit of the analog value.
Can ID. #
/Connector #
Function
Type
Description Test Voltage Packet No.
