Manitowoc Published 12-05-17, Control # 035-23 3-9
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
J2 Receptacle - Handles
2201/P52-1 DO-7 Handle B Rotation Indicator 24 Volts Nominal CAN32-1-64
2202/P52-2 DO-3 Handle C Rotation Indicator 24 Volts Nominal CAN32-1-4
2203/P52-3 DO-6 Handle D Rotation Indicator 24 Volts Nominal CAN32-1-32
2204/P52-4 DO-2 Handle A Rotation Indicator 24 Volts Nominal CAN32-1-2
2205/P52-5 DO-5 Overhead Wiper Switch 24 Volts Nominal CAN32-1-16
2206/P52-6 DO-13 Power to Switches 1 24 Volts Nominal CAN32-2-16
2207/P52-7 DO-16 Power to Switches 2 24 Volts Nominal CAN32-2-128
2208/P52-8 DO-9 Power to Switches 3 24 Volts Nominal CAN32-2-1
2209/P52-9 DO-19 Handle B Raise Direction 24 Volts Nominal CAN32-3-4
2210/P52-10 DO-12 Handle B Lower Direction 24 Volts Nominal CAN32-2-8
2211/P52-11 DO-4 Front Wiper Switch 24 Volts Nominal CAN32-1-8
2213/P52-13 DO-8-2 Handle B Display 24 Volts Nominal CAN32-1-128
2214/P52-14 Ground Handle B Display Ground
2215/P52-15 DO-1 Cab Base RCL Beacon/Alarm 24 Volts Nominal CAN32-1-1
2216/P52-16 DO-22 Handle C Raise Direction 24 Volts Nominal CAN32-3-32
2217/P52-17 DO-24 Handle C Lower Direction 24 Volts Nominal CAN32-3-128
2218/P52-18 DO-10 Handle D Lower Direction 24 Volts Nominal CAN32-2-2
2219/P52-19 DO-18 Handle D Raise Direction 24 Volts Nominal CAN32-3-2
2220/P52-20 Ground Handle D Display Ground
2221/P52-21 DO-8-3 Handle D Display 24 Volts Nominal CAN32-1-128
2222/P52-22 DO-8-4 Handle C Display 24 Volts Nominal CAN32-1-128
2223/P52-23 Ground Handle B Rotation Indicator Ground
2224/P52-24 Ground Handle C Rotation Indicator Ground
2225/P52-25 Ground Handle D Rotation Indicator Ground
2226/P52-26 DO-15 Left Travel Handle Reverse Direction 24 Volts Nominal CAN32-2-64
2227/P52-27 DO-14 Left Travel Handle Forward Direction 24 Volts Nominal CAN32-2-32
2228/P52-28 DO-11 Right Travel Handle Reverse Direction 24 Volts Nominal CAN32-2-4
2229/P52-29 DO-17 Right Travel Handle Forward Direction 24 Volts Nominal CAN32-3-1
2230/P52-30 Ground Handle C Display Ground
2231/P52-31 DO-8-5 Handle A Display/Seat Switch 24 Volts Nominal CAN32-2-128
2233/P52-33 5 Volts DC Handle B Power 5 Volts DC Nominal
2234/P52-34 5 Volts DC Handle C Power 5 Volts DC Nominal
2235/P52-35 5 Volts DC Handle D Power 5 Volts DC Nominal
2236/P52-36 DO-21 Travel Cruise Switch 0 Volts Off; 24 Volts On CAN-32-3-16
2237/P52-37 DO-23 Foot Throttle Output
Low Idle 2.9 – 3.0 Volts;
High Idle 0.9 – 1.0 Volts
CAN-32-3-64
2239/P52-39 5 Volts DC Left Travel Handle Power 5 Volts DC Nominal
2240/P52-40 5 Volts DC Right Travel Handle Power 5 Volts DC Nominal
J3 Receptacle - Power
Can ID. #
/Connector #
Function
Type
Description Test Voltage Packet No.
