Manitowoc Published 12-05-17, Control # 035-23 3-19
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
64-g Ground Jumper to Node Select 1 Ground
64-h NS-1 Node Select 1 Jumper to Ground 0 Volts (With Jumper)
64-j NS-2 Node Select 2 Jumper to Ground 0 Volts (With Jumper)
64-r Ground Jumper to Node Select 2 Ground
J6 Receptacle – Drum 2 Controls
66-A Ground Drum 2 Motor Control 1 Ground
66-B DO-7 Drum 2 Motor Control 1 See Table 3-3
for Values CAN34-1-64
66-C Ground Drum 2 Motor Control 2 Ground
66-D DO-8 Drum 2 Motor Control 2 See Table 3-3
for Values CAN34-1-128
66-E Ground Drum 2 Brake Solenoid Ground
66-F DO-9 Drum 2 Brake Solenoid 0 Volts Off; 24 Volts On CAN34-2-1
66-G Ground Drum 2 Minimum Bail Limit Switch Ground
66-H DO-10 Drum 2 Minimum Bail Limit Switch 0 Volts Off, 24 Volts On CAN34-2-2
66-J DI-8 Drum 2 Minimum Bail Limit Switch 0 Volts Off, 24 Volts On CAN61-1-128
66-K NS-1 Node Select 1 Jumper to Ground 0 Volts (With Jumper)
66-L NS-2 Node Select 2 Jumper to Ground 0 Volts (With Jumper)
66-U Ground Jumper to Node Select 2 Ground
66-V 5 Volts Drum 2 and Drum 7 Motor Speed Sensor 5 Volts DC
66-W Ground Jumper to Node Select 1 Ground
66-Z Ground Drum 2 Motor Speed Sensor Ground
66-j Ground Drum 7 Motor Speed Sensor Ground
66-n ENC-1A Drum 7 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN62-2
2
66-p ENC-1B Drum 7 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN62-2
2
66-r ENC-2A Drum 2 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
.2 Volts Moving
CAN62-4
2
66-s ENC-2B Drum 2 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN62-4
2
1
– Lower four bits are the most significant bit of the analog value.
2
– The number in the indicated bank should increase with device rotation and decrease with rotation in opposite direction.
Can ID. No.
Function
Type
Description Test Voltages Packet No.
