Manitowoc 18000 Service Maintenance Manual

Reference Only
Manitowoc Published 12-05-17, Control # 035-23 3-21
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
76-b AI-10 Swing Right Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN18-4
1
76-c AI-11 Swing Brake Pressure Sender
1 Volt at 0 psi;
5 Volts at 750 psi
CAN18-6
1
76-j Ground Swing Motor Speed Sensor Ground
76-n ENC-1A Swing Motor Speed Sensor CH A
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN64-2
2
76-p ENC-1B Swing Motor Speed Sensor CH B
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN64-2
2
1
– Lower four bits are the most significant bit of the analog value.
2
– The number in the indicated bank should increase with device rotation and decrease with rotation in opposite direction.
Can ID. No.
Function
Type
Description Test Voltages Packet No.
