18000 SERIVCE/MAINTENANCE MANUAL POWER TRAIN
7
FIGURE 7-7
Item Description
1 Rubber Reducer
2Clamp (6)
3 Air Cleaner Assembly
4 Mounting Bracket
5 Pre Cleaner
6 Service Indicator
7 Reset Button
8 Filter Access Cover
9 Air Cleaner Assembly Inlet
10 Air Cleaner Assembly Outlet
11 Primary Filter
12 Secondary Filter
3
6
5
1
1
2
7
1
4
2
2
81018951
81017660
IMG_752
IMG_753
10
9
8
11
12
