Manitowoc 18000 - Page 259

Reference Only
Manitowoc Published 12-05-17, Control # 035-23 7-15
18000 SERIVCE/MAINTENANCE MANUAL POWER TRAIN
7
A14217
81017661
Item Description
1 Cooler Assembly Tier 3 and Past Production
2 Cooler Assembly Tier 4
3 Coolant Level Sight Gauge
4
Cooler Assembly Fill Cap
5 Cooler Assembly Drain
FIGURE 7-11
3
4
4
5
5
3
2
5
1
Tier 4 Current Production
Tier 3 and Past Production
