POWER TRAIN 18000 SERIVCE/MAINTENANCE MANUAL
7-20
Published 12-05-17, Control # 035-23
Item Description
1 Lifting Hook
2 Temperature Sensor 1
3 Temperature Sensor 2
4 Lifting Hook Band
5 Inlet V-Band Clamp
6 Pressure Sensor
7 Outlet V-Band Clamp
8DPF Outlet Section
9 DPF Center Section
10 DPF Inlet Section
9
View A
View B
Outlet End
35
o
63
o
105
o
10
o
28
o
View C
Inlet End
3
32
6
2
1
1
6
FIGURE 7-15
8
10
4
5
7
