INTRODUCTION 18000 SERIVCE/MAINTENANCE MANUAL
1-44
Published 12-05-17, Control # 035-23
X
A
B
HS-7
DRUM
SUCTION
MANIFOLD
MAIN HOIST 1
DOWN
UP
340 PSI
(23 BAR)
B
A
PRESSURE
SENDER
X
X
B
A
SUCTION
MANIFOLD
DOWN
UP
340 PSI
(23 BAR)
A
B
(DRUM 1/3) PUMP
MAIN HOIST 1
(DRUM 1) PUMP
SERVO PILOT PRESSURE
FROM RIGHT TRAVEL
CHARGE PUMP
MAKE-UP CHARGE PRESSURE
X
BRAKE
DRUM
BRAKE
TO DRUM 3
SELECTOR
VALVE
DIVERTER
MAKE-UP CHARGE PRESSURE
LOW-PRESSURE SIDE
HIGH
HIGH-PRESSURE SIDE
LOW-PRESSURE SIDE
SIDE
MAIN HOIST
DRUM 1
.060
.060
PRESSURE
EQUALIZING LINE
EQUALIZING LINE
HS-9
LOW PRESSURE
ACCESSORY SUPPLY
4 GPM
(15 m/l)
OPENS AT
4 GPM
(15 m/l)
OPENS AT
200 PSI (14 bar)
200 PSI (14 bar)
FIGURE 1-29
18CSM1-127
