Manitowoc Published 12-05-17, Control # 035-23 1-59
18000 SERIVCE/MAINTENANCE MANUAL INTRODUCTION
1
VALVE BANK
LOAD EQUALIZING
VALVE
4500 PSI (310 BAR)
MAST RAISING CYLINDERS EXTEND
3500 PSI (240 BAR)
VALVE BANK
LOAD EQUALIZING
VALVE
4500 PSI (310 BAR)
3500 PSI (240 BAR)
HS-33
HS-34
HS-34
HS-33
MAST RAISING CYLINDERS RETRACT
FIGURE 1-36
18CSM1-134
18CSM1-135
From High Pressure
Accessory
Manifold
From High Pressure
Accessory
Manifold
