OPERATING PROCEDURES GRT655/655L OPERATOR MANUAL
4-52 Published 3-23-2020, Control # 654-04
46
Auxiliary Hoist
Disabled Indicator
Indicates the auxiliary hoist (optional) function is disabled (refer to
Crane Function Enable/Disable Switch, page 3-6 and Auxiliary Hoist
Enable/Disable Switch, page 3-13).
Auxiliary Hoist Standby
Indicator (Amber -
Constant On)
Indicates the auxiliary hoist (optional) function is enabled, but is in a
standby mode due to the operator not being seated (causing seat
switch to open).
The auxiliary hoist function is re-enabled by either sitting in the
operator seat or by actuating a dead-man switch on the left or right
dual axis controllers [refer to Deadman Switches (Optional) (Dual
Axis Controllers only), page 3-16].
Auxiliary Hoist Standby
Indicator (Amber -
Flashing)
Indicates the auxiliary hoist function is actuated (controller actuated)
when the auxiliary hoist function is changed from disabled to
enabled.
Allow controller to return to its neutral position, then re-enable the
auxiliary hoist function.
Auxiliary Hoist Enabled
Indicator (Green)
Indicates the auxiliary hoist (optional) function is enabled (refer to
Crane Function Enable/Disable Switch, page 3-6 and Auxiliary Hoist
Enable/Disable Switch, page 3-13).
Auxiliary Hoist Raise
Indicator (Green)
Indicates the auxiliary hoist rope is being reeled in.
Auxiliary Hoist Lower
Indicator (Green)
Indicates the auxiliary hoist rope is being let out.
Auxiliary Hoist High
Speed Indicator (Green)
Indicates the auxiliary hoist function and the high speed function are
enabled.
Item Description Graphic Explanation
