Grove Published 3-23-2020, Control # 654-04 4-51
GRT655/655L OPERATOR MANUAL OPERATING PROCEDURES
45
Main Hoist Disabled
Indicator
Indicates the main hoist function is disabled (refer to Crane Function
Enable/Disable Switch, page 3-6 and Main Hoist Enable/Disable
Switch, page 3-12).
Main Hoist Standby
Indicator (Amber -
Constant On)
Indicates the main hoist function is enabled, but is in a standby mode
due to the operator not being seated (causing seat switch to open).
The main hoist function is re-enabled by either sitting in the operator
seat or by actuating a dead-man switch on the left or right dual axis
controllers [refer to Deadman Switches (Optional) (Dual Axis
Controllers only), page 3-16].
Main Hoist Standby
Indicator (Amber -
Flashing)
Indicates the main hoist function is actuated (controller actuated)
when the main hoist function is changed from disabled to enabled.
Allow controller to return to its neutral position, then re-enable the
main hoist function.
Main Hoist Enabled
Indicator (Green)
Indicates the main hoist function is enabled (refer to Crane Function
Enable/Disable Switch, page 3-6 and Main Hoist Enable/Disable
Switch, page 3-12).
Main Hoist Raise
Indicator (Green)
Indicates the main hoist rope is being reeled in.
Main Hoist Lower
Indicator (Green)
Indicates the main hoist rope is being let out.
Main Hoist High Speed
Indicator (Green)
Indicates the main hoist function and the high speed function are
enabled.
Item Description Graphic Explanation
To Next Page
