FIGURE 5-15 continued
2 Parts Line - 1 Sheave Hook Block
Single Part Line
Boom Nose
Dead End
Lower Boom
Nose Sheaves
To Main Hoist
8993-15
Upper Boom Nose
Sheaves
To Main Hoist
Upper Boom Nose
Sheaves
Lower Boom
Nose Sheaves
8993-16
