Manitowoc Grove RT9130E-2 Service And Maintenance Manual

INTRODUCTION RT9130E-2 SERVICE MANUAL
1-6 Published 11-22-2016, Control # 345-12
Delete: Counterweight (24,000 pounds) -56.10 (-142.5) -24000 (-10886) 6922 (3140) -30922 (-14026)
Delete: Auxiliary Hoist Cable (700 ft) -62.76 (-159.4) -875 (-397) 282 (128) -1157 (-525)
Delete: Air Conditioning -21.37 (-54.3) -205 (-93) 23 (10) -228 (-103)
Delete: General 33.25 X 29 (38) Tires (for
travel)
97.25 (247.0) -9520 (-4318) -4760 (-2159) -4760 (-2159)
Heavy Counterweight Package (16000 lb) -54.03 (-137.2) 16000 (7258) -4445 (-2016) 20445 (9274)
Lift Cylinder Travel Support 224.75 (570.9) 125 (57) 144 (65) -19 (-8)
Counterweight Stand (pinned to carrier) 242.74 (616.6) 172 (78) 214 (97) -43 (-19)
26 ft Boom Extension Insert w/RCL 1437 (652)
Tire Removal Tool 545 (247)
Description
CG to CL Bogie
in (cm)
Weight
lb (kg)
Front Axle
lb (kg)
Rear Axle
lb (kg)
