HOIST AND COUNTERWEIGHT RT9130E-2 SERVICE MANUAL
5-10 Published 11-22-2016, Control # 345-12
HOIST TO BOOM ALIGNMENT
Preparation
Boom alignment (Figure 5-3) must be completed before
attempting hoist alignment. If the hoist is not properly
aligned, the cable can be damaged or fine control could be
affected.
The crane must be set on outriggers fully extended and the
crane must be leveled. The boom must be over the front.
Tools Required
• Two foot square
• Mason cord
• Chalk
• Protractor
Procedure
The hoist mounting location will determine the alignment
procedure used. Shift one side of the hoist back or forward to
align the hoist with the boom sheave. It may be necessary to
shim under one side of the hoist to make it level.
The hoist must be checked in two directions, one at 0 degree
and the other is above 45 degrees boom angle on any crane
that the hoist is not mounted directly to the boom, stationary
mounted.
Check the hoist at 0 degrees to see if the hoist is aligned to
the boom nose sheave. The main hoist is aligned to the right
hand sheave and the auxiliary hoist is aligned to the center
sheave.
NOTE: The hoist cable will have gaps on the drum during
spooling if the alignment is not correct.
The hoist is not level if the cable is piling up on one
side of the drum.
1. The boom must be extended one half of full extension on
all hoist alignments. This length is used because when
the main hoist cable is positioned on the top right hand
boom nose sheave, the cable must leave the center of
the drum at a 90 degree angle. The boom has the ability
to extend, retract, and change the angle of departure
from the drum. Extend the boom half way to provide a
center point of adjustment to check the fleet angle of the
cable.
2. All the cable must be removed from the hoist drum to
check the fleet angle. Using mason cord or fishing line
you will be able to pull the line tight to make an accurate
measurement of the fleet angle. Find the centerline of
the hoist drum by using a square and drawing a line
horizontal on the drum. Put a line vertical to the
horizontal line in the absolute center of the drum by
using a tape measure. With the boom at 0 degree, tie the
line tight to the boom nose and have it in the center of
the right hand boom nose sheave.
NOTE: If this special equipment is not available, sufficient
accuracy in locating a centerline may be obtained
by using a steel square against the machine’s inner
surfaces of both flanges. It is advisable to avoid
using any cast surfaces in this procedure unless a
check from both flanges indicates that the resultant
line is straight.
3. Tie the line around the hoist drum so that the line is very
tight and the line is crossing the absolute center of the
drum at the centerline mark you put on the drum.
4. Using a protractor, lay it on the vertical line on the hoist
drum so the string line is in the center of the protractor.
The string line will be at the 90 degree mark on the
protractor if the hoist is straight with the boom nose
sheave. If it is not at the 90 degree mark, the hoist
mounting bolts will have to be loosened and the hoist
moved so it is.
NOTE: This test is for cable leaving gaps while spooling.
5. Elevate the boom above 45 degrees boom angle to
check if the hoist is level. Reposition the hoist drum and
tighten the cord so you can have the cord in the center of
the protractor at the 90 degree mark. If the cord is not at
the 90 degree mark, the hoist will have to be shimmed
until the cord is at the 90 degree mark.
NOTE: This test is for cable piling up on one side of the
hoist drum.
CAUTION
Do not alter holes or stop blocks on the crane mounting
plate, as very small adjustments result in large angular
changes. Extreme care should be taken to avoid over-
correction.
