Grove Published 11-22-2016, Control # 345-12 9-31
RT9130E-2 SERVICE MANUAL LUBRICATION
Instructions for Accessing Lubrication
Points on Boom
Table 9-4Accessing Lubrication Points on Boom
1. Set RCL operating code to 0001.
2. Set auto boom mode. Extend the boom sections to gain
access to the Lubrication points as indicated in the table
above for “Auto Mode”. The RCL system will lockout at
approximately 145 ft boom extension.
3. After performing the lubrication requirements accessible
in one of the above, fully retract all boom sections.
4. Set boom configuration to manual boom mode and
select the center mid switch to fully extend the center
mid section.
5. Fully extend the center mid section.
NOTE: During this extension you must override the RCL
system.
6. Once the center mid is fully extended, continue
extending the outer mid and fly section to reach the
points indicated in the table above. The center, outer,
and fly section lube points may be fully extended during
this step.
7. Once lubrication is complete, fully retract all boom
sections and return boom to auto boom mode.
Item Boom Section Access Location
Auto
Mode
Manual
Mode
Inner
Mid %
Center
Mid %
Outer
Mid %
74 Inner Large hole in center & outer mid N/A Yes 0 100 60
74 Inner Large hole in inner mid Yes N/A 100 75 0
75 Outer mid & fly Small holes on the sides N/A Yes 0 100 100
75 Inner mid Small holes on the sides Yes N/A 100 75 0
75 Center mid Small holes on the sides Yes N/A 100 100 0
76 Center, outer mid & fly External on the boom N/A Yes 0 100 100
76 Inner mid External on the boom Yes N/A 100 75 0
77 Extend cable sheaves
Small hole left side on the front of the
outer mid
N/A Yes 0 100 100
78 Retract cable sheaves
Oblong holes at the end of the center
mid
N/A Yes 0 100 100
WARNING
Do NOT extend the inner mid. The inner mid must remain
fully retracted.
To Next Page
