Grove Published 11-22-2016, Control # 345-12 9-27
RT9130E-2 SERVICE MANUAL LUBRICATION
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Hoist
90 Main Hoist Figure 9-11
AGMA
Extreme
Pressure Gear
Lubricant
6829100213
22 qt
(20.8 l)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass. (See note)
Remove hose at top of
sight gauge. Fill hoist
through hose until fluid
is at full mark on sight
gauge.Variations in oil
temperature will cause
oil level to fluctuate.
91 Auxiliary Hoist Figure 9-11
AGMA
Extreme
Pressure Gear
Lubricant
6829100213
22 qt
(20.8 l)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
NOTE: To check hoist oil, ensure hoist is level and the fill plug is horizontal and centered in access hole at the 9:00 position.
The oil must have settled for 20 minutes with the temperature in 70°F +/- 20°F range.
If oil level is not visible in sight glass, the hoist may be underfilled. Oil escaping from vent plug is an indication the
hoist may be overfilled.
92
Cable Follower
(Arms)
(Figure 9-1
1)
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Thoroughly
coat
250 hours or 3 months Spray on
NOTE: Lubricate more frequently than interval indicated in table if environmental conditions and/or operating conditions
necessitate.
