7-24 Published 11-22-2016, Control # 345-12
POWER TRAIN RT9130E-2 SERVICE MANUAL
7. Connect the two radiator tubes to the radiator with hose
clamps and the radiator hose.
8. Secure the radiator tube to the top of the engine using
nuts, washers and a muffler clamp.
9. Reinstall surge tank and connect the hoses between the
surge tank and engine and the surge tank and the
radiator.
10. Tighten the drain cock at the bottom of the radiator drain
hose.
11. Install the hood assembly.
12. Install the hardware holding the rear engine hood panel
to the engine hood.
13. Install the hood top door assembly.
14. Service the engine coolant system as necessary, See
Engine Antifreeze/Coolant Fill Procedure (when level is
low), page 7-19. Refer to Lubrication, page 9-1. Start the
engine, operate all systems and check for leaks.
Item Description
1 Air Bleed Pet Cock
2 Upper Radiator Tube
3 Hose Clamp
4 Radiator Hose
5 Overflow Hose
6 Surge Tank Cap
7 Surge Tank
8 Fan Shroud
9Fan
10 Radiator
11 Fan Guard
12 Radiator Hose
13 Radiator Stabilizer
14 Radiator Hose
15 Lower Radiator Tube
16 Drain Cock
17 Drain Hose
18 Radiator Hose, Elbow
Item Description
