OPERATING CONTROLS AND PROCEDURES MLC300 OPERATOR MANUAL
3-56
Published 11-20-19, Control # 234-19
Figure 3-8. Right-Side Cab Window
View A View B
Item Description
1 Window Latch Handle
Figure 3-9. Cab Tilt Stop Pin
Item Description
1Cab
2 Cab Support
3 Safety Pin (2)
4Stop Pin (2)
5Stop Bolt
WORKING
Position
SHIPPING
Position
WORKING Position
Two Places
