SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-26
Published 11-20-19, Control # 234-19
Figure 4-23
View A — STORED
View B
ROTATING BED WORKING and
STANDALONE
View C
STANDALONE
View D
ROTATING BED WORKING
Item Description
1 Left-Rear Platform
2 Top Ladder
3 Bottom Ladder
4 Ladder Hook (2)
5 Pin with Hair-Pin Cotter (2)
6 Pin with Hair-Pin Cotter (3)
7 Ladder Support Bracket
8 Rotating Bed Lug
9 Padlock
