SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-32
Published 11-20-19, Control # 234-19
Item Description
1Live Mast
2 Keeper Pin with Safety Pin (4)
3 Mast Hinge Pin
4 Equalizer Hinge Pin
5 Pin with Safety Pin (4)
6 Boom Hoist Mounting Frame
7 Alignment Lug (2)
8 Alignment Ring (2)
9 Rotating Bed Lug (2)
10 Alignment Pin (4)
11 Alignment Notch (4)
12 Rotating Bed Frame
13 Alignment Lug (2)
14 Boom Hoist Equalizer
15 Alignment Ring (2)
16 Rotating Bed Lug (2)
17 VPC Trolley
18 Stop Block (2)
Figure 4-26
View A1
STORED
View C
View B1
WORKING
See Views D and E
Page 33
View B2
WORKING
View A2
STORED
OR
OR
