SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-50
Published 11-20-19, Control # 234-19
Figure 4-37
Item Description
1 Trailer (single-drop deck)
2 First Crawler Installed and Lowered to Ground
3 Second Crawler
7,3 m (24 ft) Radius
Item Description
1 Ladder
2 Bracket (2)
3 Quick-Release Pin (2)
Figure 4-38
