SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-52
Published 11-20-19, Control # 234-19
Item Description
1 Carbody Jack (4)
2Pin (4)
3 Jack Pad (4)
4 Storage Pin (4)
A Working Hole
B Storage Hole
Figure 4-39
View A
View B
View C
