SETUP AND INSTALLATION MLC300 OPERATOR MANUAL

4-80

Published 11-20-19, Control # 234-19

Item Description

1-4 Not Used

5 Insert (with sheaves)

6-9 Not Used

10 Insert

11 Fixed Horizontal Pin (2 each section)

12 Hooked Connector (2 each section)

13 Pin with Safety Pin (2 each section)

14 Storage Tube (2 each section)

View A

Figure 4-58

View B

Important: Pins are not

required in these holes.

NOTE The first three inserts after the boom butt can

be either standard width inserts OR 3.5 m wide

inserts, depending on the Boom Rigging

Drawing being used.
