SETUP AND INSTALLATION MLC300 OPERATOR MANUAL

4-86

Published 11-20-19, Control # 234-19

Figure 4-62

Item Description

1 Shackle (2): 25 t (28 USt)

2 Lifting Sling (4): 2,8 m (9 ft) long

3 Self-Erect Cylinder

4 Trailer (single drop deck)

5Not Used

6 Lifting Lug (4)

7-9 Not Used

10 Insert

11 Fixed Horizontal Pin (2 each section)

12 Hooked Connector (2 each section)

13 Pin with Safety Pin (2 each section)

14 Storage Tube (2 each section)

15 Boom Top

16 Stand (2)

View D

View E

View A

View B

View C

6,5 m (21 ft) Radius

Important: Pins are not

required in these holes.
