SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-90
Published 11-20-19, Control # 234-19
Figure 4-65
Item Description
1Strap
2Link
3 Pin with Safety Pins
4 Bracket
5 Pin with Collar, Retaining Pin, and Cotter Pins
6 Strap Bracket
7 Pin with Safety Pin and Flat Washer
8
Intermediate
Suspension Link (2)
9 Pin with Safety Pins
10 Bracket
Jib Backstay Straps, If Equipped (typical)
View C
View A1
SHIPPING
OR
OR
View A2
SHIPPING
View B1
WORKING
View B2
WORKING
