SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-100
Published 11-20-19, Control # 234-19
Figure 4-70
Item Description
1 Mast Assist Arm (2)
2Live Mast
3 Self-Erect Cylinder
4 Lifting Link
5 Storage Lug (2)
6 Pin with Cotter Pins (2)
7 Bracket (2)
8 Pin with Collar, Retaining Pin, and Cotter Pins
9Link (4)
10 Live Mast Strap (2)
11 Boom Strap
FULLY
LOWERED
FULLY
RAISED
View A
View B
View C
View D
View E
