SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-170
Published 11-20-19, Control # 234-19
Figure 4-114
Item Description
1Drum 1
2Drum 2*
3Drum 3*
4 Wire Rope Guide on 12 m (3.5 ft) Insert
5 Wire Rope Guide in 12 m (3.5 ft) Insert
6Drum 6
7 Wire Rope Guide on Boom Top
8 Lower Boom Point
9 Upper Boom Point
Refer to the Reeving Diagrams at the end
of this section for rope routing over the
boom top wire rope guide (7).
- Reference Drawing 80124233
Drum 2 and 3 wire rope guide sheave
reeving is reversed for clamshell operation.
