National Crane 01-22-2019 Control # 051-08 7-1
1300A OUTRIGGERS
7
SECTION 7
OUTRIGGERS
SECTION CONTENTS
Outrigger Description. . . . . . . . . . . . . . . . . . . . . . . 7-1
Outrigger Beam Assembly. . . . . . . . . . . . . . . . . . . 7-1
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Extension Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Stabilizer Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Wear Pad Adjustment . . . . . . . . . . . . . . . . . . . . . . . 7-5
Outrigger Beam Wear Pad Adjustment . . . . . . . . . 7-6
Outrigger Box Wear Pad Adjustment. . . . . . . . . . . 7-6
Nonadjustable Wear Pad. . . . . . . . . . . . . . . . . . . . 7-6
Outrigger Monitoring System (OMS) (Optional—
Standard in North America) . . . . . . . . . . . . . . . . . . 7-7
String Potentiometer . . . . . . . . . . . . . . . . . . . . . . . 7-7
OUTRIGGER DESCRIPTION
The outriggers are used to provide stability for the truck
when the crane is in use. The outriggers can be used in the
fully retracted, at the mid-extended position, or the fully
extended position.
When the outrigger extension is activated, it extends or
retracts the outrigger beam within the outrigger box. The
outrigger beam can be extended to the mid-extend position
by allowing the lock pin to ride on the top of the beam while
it’s extending. The lock pin drops into the hole when the
beam reaches the mid extend position.
OUTRIGGER BEAM ASSEMBLY
The outrigger beam assembly consists of the following:
outrigger beams
stabilizer cylinders
required hoses and mounting hardware
