LUBRICATION 1300A
8-6 01-22-2019 Control # 051-08
Internal Cable Sheave Lubrication
A grease gun adapter is required to lubricate the internal
sheaves. The required needle grease gun fitting is:
• A 0.25 inch (6.35 mm) diameter nozzle grease gun tip
(National P/N 955045).
• Contact Manitowoc Crane Care to obtain this tip.
Lubrication of the extend and retract sheaves is as follows:
1. Extend the boom until the grease access holes on the
side of the 2
nd
and 3
rd
sections are lined up.
2. Lubricate the pin for the extend cable sheaves (18)
(Figure 8-1) until a small amount of grease extrudes
from the pin. From in front of the boom, look back
through the sheave case at the pin to determine the
amount of grease.
3. This position also aligns the access holes in the rear of
the 1
st
and 2
nd
sections for lubrication.
4. Lubricate the pins for the retract sheaves until a small
amount of grease extrudes from the sheave pins. From
in back of the boom, look up through the hoist mount at
the pins to determine the amount of grease.
Inner Boom Wear Pad Lubrication
Recommended lubricant is EP-3MG grease.
1. Fully extend and set the outriggers.
2. With the boom fully retracted, remove the access
plate (6) located on the top rear of the 1
st
section
(Figure 8-2).
3. Apply grease to the wear pads on the top of the 2
nd
section through the access holes (4) in the 1
st
section
with a grease gun (Figure 8-2).
10b Hoist brake HYDO
Check and fill
Change
Brake check and fill: As part of daily
crane inspection, check the hoist for
visible leaks.
Brake change: Every 1000 hours or
6 months.
11 Swing drive gearbox GL-5
Check and fill
Change
Check and fill: As part of daily crane
inspection, check the swing gearbox
for visible leaks.
Change: After first 50 hours of
operation and at 500 hour intervals
thereafter.
12 Swing gear teeth EP-OGL Spray Can Monthly
13 Boom extension LTG
Brush, roller or grease
gun spray can
Monthly or as required
14 Outrigger beams, bottom, sides LTG
Brush or roller spray
can
Monthly or as Required
15 Wire rope (loadline) EP-OGL Brush or spray Semi-Annually
16 Diffuser strainer, Hydraulic oil reservoir Clean Semi-Annually with Oil Change
18 Extend Sheaves EP-3MG Grease Gun Weekly
19
Retract Sheaves: Extend the boom until
the retract sheave grease holes are
visible through the access holes along
side of boom.
EP-3MG Grease Gun Weekly
20 Wire Rope (Extension Cables) WRL Spray or Brush
Any Time Boom is Disassembled or
5 Years
Item Application
Recommended
Lubricant
Procedure Frequency
DANGER
Do not, under any circumstances, work at an elevated
height without using proper fall protection as required by
local, state or federal regulations.
!
