Manitowoc National Crane 1300A Service And Maintenance Manual

CRANE INSTALLATION 1300A
9-22 01-22-2019 Control # 051-08
SPECIFICATIONS
Hydraulic System
Requirements:
Boom Lift Up/Down..................................................... 29 GPM (98 LPM), 3600 psi +100/-0 (24.8 MPa +689/-0 kPa)
Boom Telescope Out .................................................. 29 GPM (98 LPM), 2800 psi +100/-0 (19.3 MPa +689/-0 kPa)
Boom Telescope In ..................................................... 29 GPM (98 LPM), 2950 psi +100/-0 (20.3 MPa +689/-0 kPa)
Hoist System ............................................................. 34 GPM (129 LPM), 3300 psi +100/-0 (22.75 MPa +689/-0 kPa)
Outrigger .................................................................... 14 GPM (53LPM), 3000 psi +100/-0 (20.68) MPa +689/-0 kPa)
Swing.......................................................................... 12 GPM (53 LPM), 3000 psi +100/-0 (20.68 MPa +689/-0 kPa)
Reservoir Capacity ..................................................... 76 gal. (287.6 L) at full mark
System Capacity ........................................................ 125 Gallons (473 L)
Filtration ..................................................................... 10 Micron (Return Filter)
Flow rates listed are at free flow condition (approx. 100 psi / 698 kPa)
Hoist System
Wire cable .................................................................. Standard 325 ft (99 m) of 9/16 in. (14.3 mm) dia. Rotation
Resistant Nominal Breaking Strength - 38,500 lbs. (17,463 kg)
STABILITY TEST LOADS (No Jib on Side of Boom)
Test Load Start Position
(Rotate 360°)
Boom Length
ft (m)
Rated Radius
ft (m)
Rated Load
lb (kg)
Rated
Load x 1.18
lb (kg)
Model 1369A Boom
Over Back 30.6 (9.3) 25 (7.6)
16550
(7506.9)
19529
(8858.2)
Over Front 69 (21) 60 (18.3)
4350
(1973.1)
5133
(2328.2)
Over Side 69 (21) 45 (13.7)
7350
(3333.9)
8673
(3934.0)
Model 13100A Boom
Over Back 44 (13.4) 30 (9.1)
12300
(5579.1)
14514
(6583.4)
Over Front 100 (30.48) 95 (28.95) 750 (340.2) 885 (401.4)
Over Side 100 (30.48) 70 (21.3)
2700
(1224.7)
3196
(1449.1)
Model 13110A Boom
Over Back 46 (14) 35 (10.6)
9600
(4354.4)
11328
(5183.2)
Over Front 110 (35.5) 85 (25.9)
1250
(566.9)
1475 (669)
Over Side 110 (35.5) 65 (19.8)
3200
(1451.5)
3776
(1712.7)
Includes the weight of slings and hook block.
