Manitowoc National Crane 1300A Service And Maintenance Manual

National Crane 01-22-2019 Control # 051-08 8-1
1300A LUBRICATION
8
SECTION 8
LUBRICATION
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Environmental Protection . . . . . . . . . . . . . . . . . . . 8-1
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Arctic Conditions Below -9°C (15°F). . . . . . . . . . . 8-1
Chassis Grease . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Low Temperature Grease . . . . . . . . . . . . . . . . . . . 8-2
Extreme Pressure Multipurpose Gear
Lubricant (EPGL) . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Open Gear Lubricant . . . . . . . . . . . . . . . . . . . . . . 8-2
Antifreeze/Coolant (for Cab Heater) . . . . . . . . . . . 8-2
Anti-wear Additives . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Standard Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . 8-2
Arctic Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Hydraulic Oil Inspection . . . . . . . . . . . . . . . . . . . . 8-3
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Lubrication Points . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Internal Cable Sheave Lubrication. . . . . . . . . . . . . 8-6
Inner Boom Wear Pad Lubrication. . . . . . . . . . . . . 8-6
Side and Bottom Boom Wear Pad Lubrication . . . 8-7
Hoist Brake Oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
Hoist Gearbox Oil Level Check . . . . . . . . . . . . . . . 8-8
Hoist Gearbox Oil Change. . . . . . . . . . . . . . . . . . . 8-8
Swing Gearbox and Brake Oil . . . . . . . . . . . . . . . . 8-9
1300A Hydraulic Oil Reservoir Level . . . . . . . . . . . 8-9
Wire Rope Lubrication . . . . . . . . . . . . . . . . . . . . . . 8-9
Carwell© Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 8-10
Protecting Cranes from Corrosion . . . . . . . . . . . . 8-10
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 8-11
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 8-11
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 8-12
GENERAL
To ensure a maximum crane lifetime and utilization, follow a
designated lubrication procedure. The procedures and
lubrication charts in this section include information on the
types of lubricants used, the location of the lubrication points,
the frequency of lubrication, and other information.
Lubrication requirements for the truck chassis are not
included here. Refer to appropriate truck manufacturer's
manual for this information.
The service intervals specified are for normal operation with
moderate temperature, humidity, and atmospheric
conditions. In areas of extreme conditions, the service
periods and lubrication specifications need to be altered for
existing conditions. For information on extreme condition
lubrication, contact your local National Crane Distributor or
Manitowoc Crane Care.
ENVIRONMENTAL PROTECTION
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
Potentially harmful waste used in National Cranes includes
— but is not limited to — oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
• Immediately clean up any spills.
Lubricants
Specific recommendations of brand and grade of lubricants
are not made here due to regional availability, operating
conditions, and the continual development of improved
products. Where questions arise, contact your National
Crane Distributor or Manitowoc Crane Care.
Arctic Conditions Below -9°C (15°F)
In general, petroleum based fluids developed especially for
low temperature service may be used with satisfactory
