National Crane 01-22-2019 Control # 051-08 9-23
1300A CRANE INSTALLATION
Crane Operating Speeds
Rotation, 375° ............................................................ 30 sec. ±5 sec.
Boom Up, (-10° to 80°) .............................................. 24 sec. ±5 sec.
Boom Down, (80° to -10°) .......................................... 22 sec. ±5 sec.
Boom Extend (22 ft to 69 ft) ........................................ 60 sec. ±10 sec.
Boom Retract (22 ft to 69 ft)........................................ 70 sec. ±10 sec.
Boom Extend (29 ft to 100 ft) ...................................... 90 sec. ±10 sec.
Boom Retract (29 ft to 100 ft)...................................... 100 sec. ±10 sec.
Boom Extend (33 ft to 110 ft) ...................................... 100 sec. ±10 sec.
Boom Retract (33 ft to 110 ft)...................................... 110 sec. ±10 sec.
Outrigger Beam Extend .............................................. 8 sec. ±3 sec.
Outrigger Beam Retract.............................................. 7 sec. ±3 sec.
Outrigger Jack Extend ................................................ 14 sec. ±3 sec.
Outrigger Jack Retract................................................ 13 sec. ±3 sec.
Crane operating speeds based on engine speed at governed
RPM and hydraulic reservoir temperature at 100°F (37.7°C).
Air Conditioner (Optional)
Hydraulic Requirements .........................................................30.28 LPM (8 GPM) @ 10.34 MPa (1500 PSI Max)
Minimum Evacuation Time .................................................... 30 minutes
Refrigerant Charge Levels .................................................... 2.0 pounds (+/- 0.5 Ounce)
Additional Pag Oil Required Above 6 ounces in Compressor 4.0 ounces
Hoist Performance (with 1 part of line)
Layer
Hoist Pull Hoist Speed BOS Hoist Speed
lbs (kg) fpm (mpm) fpm (mpm)
1 10,200 (4626) 111 (33.8) 206 (62.7)
2 9,200 (4173) 123 (37.4) 228 (69.4)
3 8,400 (3810) 135 (41.1) 251 (76.5)
4 7,700 (3492) 147 (44.8) 273 (83.2)
5 7,100 3220 159 (48.4)
All ratings based on 34 GPM at 3300 psi. (129 LPM at 22.75 MPa)
Burst of Speed maximum pull = 3000 lbs. (1361 kg)
