National Crane 03-20-2019 Control # 613-06 1-3
NBT30H-2 SERVICE MANUAL INTRODUCTION
1
10
FIGURE 1-2
Item Component
1 Control Console
2 RCL Display
3 Operators Station
4 Rated Capacity Limiter (RCL) Reel
5 Boom
6 Boom Nose
7 Boom Rest
8 Lift Cylinder
9Hoist
10 Outrigger Beam
11 Outrigger Box
12 Rear Stabilizer Out and Down (RSOD)
13 Extension
14 Turret
15 Single Front Outrigger-(SFO)
16 Hydraulic Tank
17 Hydraulic Pump
18 Radio Remote Receiver
19 Truck Frame
20 Truck Bed
21 Torsion Box, T-Box
22 Sheave
23 RSOD Foot
Item Component
6
22
10
13
6
18
3
12
7
6
5
8
1
20
21
19
16
11
15
23
17
4
14
9
8596-2
2
8606-1
1
2
3
14
11
