Manitowoc National Crane NBT30H-2 Service Manual

8
National Crane 03-20-2019 Control # 613-06 8-1
NBT30H-2 SERVICE MANUAL LUBRICATION
SECTION 8
LUBRICATION
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Environmental Protection . . . . . . . . . . . . . . . . . . . 8-1
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Arctic Conditions Below -9°C (15°F). . . . . . . . . . . 8-1
Chassis Grease . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Low Temperature Grease . . . . . . . . . . . . . . . . . . . 8-2
Extreme Pressure Multipurpose Gear Lubricant
(EPGL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Open Gear Lubricant . . . . . . . . . . . . . . . . . . . . . . 8-2
Antifreeze/Coolant (for Cab Heater) . . . . . . . . . . . 8-2
Anti-wear Additives . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Standard Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . 8-2
Arctic Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Hydraulic Oil Inspection . . . . . . . . . . . . . . . . . . . . 8-3
Surface Protection for Cylinder Rods . . . . . . . . . . 8-3
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Internal Cable Sheave Lubrication. . . . . . . . . . . . . 8-7
Inner Boom Wear Pad Lubrication. . . . . . . . . . . . . 8-7
Side and Bottom Boom Wear Pad Lubrication . . . 8-7
Outrigger Beam Lubrication. . . . . . . . . . . . . . . . . . 8-8
Hoist Brake Oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Hoist Gearbox Oil . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Swing Gearbox and Brake Oil . . . . . . . . . . . . . . . . 8-9
Hydraulic Oil Reservoir Level . . . . . . . . . . . . . . . 8-10
Wire Rope Lubrication . . . . . . . . . . . . . . . . . . . . . 8-10
Carwell© Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 8-11
Protecting Cranes From Corrosion . . . . . . . . . . . 8-11
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 8-11
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 8-12
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 8-13
GENERAL
Following a designated lubrication procedure is important to
ensure maximum crane life. The procedures and lubrication
charts in this section include information on the types of
lubricants used, the location of the lubrication points, the
frequency of lubrication, and other information. This section
does not include lubrication requirements for the truck
chassis. Refer to the truck service manual for this
information.
The service intervals specified are for normal operation
where moderate temperature, humidity, and atmospheric
conditions prevail. In areas of extreme conditions, the
service periods and lubrication specifications should be
altered to meet existing conditions. For information on
extreme condition lubrication, contact your local National
Crane distributor or Manitowoc Crane Care.
Environmental Protection
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
Potentially harmful waste used in Manitowoc cranes includes
— but is not limited to — oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
• Immediately clean up any spills.
Lubricants
Specific recommendations of brand and grade of lubricants
are not made here due to regional availability, operating
conditions, and the continual development of improved
products. Where questions arise, contact your National
Crane Distributor or Manitowoc Crane Care.
Arctic Conditions Below -9°C (15°F)
In general, petroleum based fluids developed especially for
low temperature service may be used with satisfactory
results. However, certain fluids, such as halogenated
hydrocarbons, nitro hydrocarbons, and phosphate ester
