1-16 03-20-2019 Control # 613-06
INTRODUCTION NBT30H-2 SERVICE MANUAL
M6x1.0
8.8 8.3 8.1 7.9
10.9 12.2 11.9 11.6
12.9 14.3 13.9 13.6
M8x1.25
8.8 20.2 19.7 19.2
10.9 29.6 28.9 28.2
12.9 34.7 33.8 33.0
M10x1.5
8.8 40.0 39.0 38.0
10.9 58.7 57.2 55.8
12.9 68.7 67.0 65.3
M12x1.75
8.8 69.7 68.0 66.2
10.9 102.4 99.8 97.2
12.9 119.8 116.8 113.8
M14x2
8.8 111.4 108.6 105.8
10.9 163.6 159.5 155.4
12.9 191.5 186.7 181.9
M16x2
8.8 172.8 168.5 164.1
10.9 253.8 247.4 241.1
12.9 296.9 289.5 282.1
M18x2.5
8.8 246.2 240.1 233.9
10.9 350.7 341.9 333.2
12.9 410.4 400.1 389.9
M20x2.5
8.8 348.0 339.3 330.6
10.9 495.6 483.2 470.8
12.9 580.0 565.5 551.0
M22x2.5
8.8 474.4 462.6 450.7
10.9 675.7 658.8 641.9
12.9 790.7 770.9 751.2
M24x3
8.8 601.3 586.3 571.3
10.9 856.4 835.0 813.6
12.9 1002.2 977.1 952.1
M27x3
8.8 881.6 859.6 837.5
10.9 1255.7 1224.3 1192.9
12.9 1469.4 1432.7 1395.9
M30x3.5
8.8 1195.3 1165.5 1135.6
10.9 1702.5 1659.9 1617.3
12.9 1992.3 1942.4 1892.6
Nominal Size, Threads per
Inch, and Series
Designation
Property
Class
Torque (Nm)
Maximum Nominal Minimum
