Reserved Local Bit (LB) Table
Address Function Access Description
9000-9009 On after OIT reset R/W
These bits can be used for any object that needs to be initially set
when OIT is initialized.
9010 Recipe Download Indicator RdOnly This bit is set when a recipe is downloading to the PLC
9011 Recipe Upload Indicator RdOnly This bit is set when a recipe is uploading from a PLC
9012
Recipe Download/Upload
Indicator
RdOnly This bit is set when a recipe is download or uploaded to a PLC
9013 Taskbar Touch indicator RdOnly This bit is set when the touch indicator on the taskbar is pressed.
9014 Taskbar CPU indicator RdOnly This bit is set when the CPU indicator on the taskbar is pressed.
9015 Taskbar Alarm indicator RdOnly This bit is set when the Alarm indicator on the taskbar is pressed.
9016 Printer Error Indicator RdOnly This bit is set when the OIT is unable to print to the printer.
9017 Printer Control Bit R/W
This bit can be used to temporarily disable the printer port on the
OIT. Set the bit to disable the printer port. Clear the bit to
enable.
Note: You must enable the printer option in the Edit…Set System
Parameters…General tab menu of EasyBuilder.
9018,9019 Reserved for future use
9020 Message Board- Pen option R/W Set this bit to select Pen mode for the Message Board feature
9021 Message Board- Brush option R/W Set this bit to select Brush mode for the Message Board feature
9022 Message Board- Clip option R/W Set this bit to select Clip mode for the Message Board feature
9023-9029 Reserved for future use
9030 Message Board- Pen width = 1 R/W
Set this bit to select Pen Width = 1 pixel for the Message Board
feature
9031 Message Board- Pen width = 2 R/W
Set this bit to select Pen Width = 2 pixels for the Message
Board feature
9032 Message Board- Pen width = 3 R/W
Set this bit to select Pen Width = 3 pixels for the Message Board
feature
9033-9039 Reserved for future use
9040 Hide Fast SelectionWindow R/W
Set this bit to hide the Fast Selection window; clear it to display
the Fast Selection window
9041 Hide TaskBar R/W
Set this bit to hide the TaskBar window; clear it to display the
TaskBar window
9042 Hide TaskBar Buttons R/W
Set this bit to hide the TaskBar buttons; clear it to display the
TaskBar buttons
9043
Hide All (Fast Select,TaskBar,
and TaskBarButtons)
R/W
Set this bit to hide the Fast Selection window, the TaskBar
window, and the TaskBar buttons; clear it to display the three
objects
9044
Restore system parameters from
recipe words
R/W
Set this bit ON will restore these system parameters from
Reserved Recipe Word. After a restore, the system will clear this
bit off.
9045 Reset OIT
Write
only
Set this bit ON to reset (warm boot) the OIT. After a reset, the
OIT reboots and clears this bit.
9046 Low Security Level R/W
Security Error: Latches to a 1 when there is an attempt to enter a
higher security level page when the security level is not set. User
must clear it.
9047-9049 Reserved for future use
9050 Toshiba Protocol: T© control bit R/W
For Toshiba protocol driver. When this bit is on, write T© as ON
Or OFF T1/T1S user's manual. NOTE: In case of Timer/Counter
register write, the Timer/Counter's device data (2 bytes each)
corresponding to the Timer/Counter's register should be added.
If the Timer/Counter's device is set to ON, it should be '01'.
Otherwise, it should be 00.
9051
TouchScreen Control during
disabled backlight
R/W Set this bit to disable the touch screen when the backlight is off.
1010-1001a, Rev 02
164 Sil ver Se ries In stal la tion & Op er a tion Man ual
