60004
Real Time Clock (RTC);
Month
R/W
This register is used to store the month for the optional RTC;
BCD code, valid values 0-11
60005
Real Time Clock (RTC);
Year
R/W
This register is used to store the year for the optional RTC; BCD
code, valid values 0-9999
60006
Real Time Clock (RTC);
Day of the Week
R/W
This register is used to store the day of the week for the optional
RTC; BCD code, valid values 0-6 (with 0=Sunday)
Non-vol a tile Stor age of Sys tem Pa ram e ters
System Parameters can be stored in the non-volatile memory held in the Recipe module. To enable this feature, see
the Hardware tab of the Set System Parameters dialog. Under the Edit menu, select System Parameters.
 The OIT must be restarted in order to activate any changes.
The System Parameters are divided into three groups: PLC Settings, General Settings, Security Settings.
PLC Settings
Address Function Description
60040 Serial port 0:RS232, 1:RS485
60041 Baud Rate 0:9600, 1:192002:38400, 3:576004:115200
60042 Data Bits 0:7, 1:8
60043 Parity 0:none, 1:even, 2:odd
60044 Stop Bits 0:1, 1:2
60045 HMI Station Address 0-255
60046 PLC Station Address 0-255
60047 Multiple HMI 0:none, 1:master, 2:slave
60048 HMI-HMI link speed 0:38400, 1:115200
60049 PLC time out constant
60050 PLC block pack
General Settings
Address Function Access Description
60051 Task button: Attribute
60052 Task button: Position
60053 Task button: background color
60054 Task button: Text
60055 Alarm bar: Pixel per scroll
60056 Alarm bar: Scroll speed
60057 Number of windows
60058 Reserved
60060 Startup window No.
60061 Backlight saver R/W
This register is used to change the timer on the backlight saver
mode. (0=disable - Backlight is on all the time; 1-255=minutes
before the backlight goes off.)
60062 Cursor color
60064 Buzzer Enable R/W
This register can change the state of the internal buzzer.
(0=disable buzzer from sounding; 1=enable buzzer to sound
when screen is touched).
60065 Common window: popup window
