Im port ing and Ex port ing the La bel Library
This feature allows you to save the labels from the label library into a .lbl file format. Once saved, the file can be
loaded into another project.
4To save the label library:
1. Click on Save Label File... The open dialog box appears.
2. Enter the name of the file where you wish to save the data.
3. Click Open.
4To load the label library from an existing .lbl file:
1. Click Load Label File... The Open dialog box appears.
2. Browse for the lbl file that contains the labels.
3. Click Open.
 The .lbl file format can not be edited.
The label library can also be imported and exported using a comma-separated variable (.csv) file format. This
format is very useful if you need to make several changes to the database. When creating a new project, it is easier
and faster to create tags as .csv files.
4To export the label library:
1. Click Export CSV File… The Open dialog box appears.
2. Enter the name of the file where you wish to save the data.
3. Click Open.
4To import the label library:
1. Click Import CSV File… The Open dialog box appears.
2. Browse for the CSV file that contains the labels.
3. Click Open.
Using the La bel Li brary
Once entries have been made to the Label Library, they can be used with any object that supports text field labeling.
1. Select an object that supports text field labeling as required. On the Label tab for the object’s
Attributes, check the Use Label Library checkbox. The Label Index list will be enabled,
containing all of the labels in the database.
