H. Span: 1 to 32767 The value at which the plot will reach the right side of the Horizontal Axis.
V. Zero: 1 to 32767 The value at which the plot will reach the bottom of the Vertical Axis.
V. Span: 1 to 32767 The value at which the plot will reach the top of the Vertical Axis.
6. Click OK to close the Create XY Plot Object dialog box. The main screen of EasyBuilder
appears with the cursor tied to a rectangular outline of the part you just created at the upper
left corner of the screen. Move the part to the desired location. You may want to create a
Rectangle Object that is displayed behind the XY Plot if the XY Plot is shown in a window
screen with other objects.
7. Once the part is placed onto the window, you can adjust the attributes of the XY Plot by
double-clicking on the part.
1010-1001a, Rev 02
