Marantz SA12 - Page 157

199
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PF16-RC-6 IN / OUT
CIRCUIT BOARD
PF16-CAPACITORS
CF01 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CF03 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
CF51 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CF52 4822 126 11568 CER. 470pF GR39 DK96471300
PF16-RESISTORS
RF01 4822 051 30472 CHIP 4.7k ±5% 1/16W NN05472610
RF02 4822 117 12925 CHIP 47k ±5% 1/16W NN05473610
RF03 4822 051 30101 CHIP 100 ±5% 1/16W NN05101610
RF51 4822 117 12139 CHIP 22 ±5% 1/16W NN05220610
RF52 4822 051 30103 CHIP 10k ±5% 1/16W NN05103610
RF53 4822 051 30222 CHIP 2.2k ±5% 1/16W NN05222610
RF54 4822 051 30103 CHIP 10k ±5% 1/16W NN05103610
PF16-SEMICONDUCTORS
DF01 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
QF01 4822 130 61554 CHIP TRS. 2SA1586 Y G HX115862B0
QF51 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
PF16-SEMICONDUCTORS
JF52 4822 267 41009 TERMINAL 2P RCA PIN JACK YT02020890
LF01 4822 157 10416 BLM11B102S 1608 EMI FILTER FN31010030
SF51 4822 277 21559 SLIDE SW. INT/EXT SS02021150
PH16-POWER SUPPLY
CIRCUIT BOARD
PH16-CAPACITORS
C803 4822 124 41458 ELECT. 4700µF 16V RA2 OA47801620
C805 4822 124 22039 ELECT. 220µF 16V ARA OA22701650
C806 4822 124 41458 ELECT. 4700µF 16V RA2 OA47801620
C815 F 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C815 N 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
C815 S 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
C815 U 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C817 F 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C817 U 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C818 N 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
C818 S 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
C823 9965 000 00605 ELECT. 3300µF 25V ±20% HIFI OB33802510
C824 9965 000 00605 ELECT. 3300µF 25V ±20% HIFI OB33802510
C827 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
C828 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
C829 F 4822 124 11574 ELECT. 1000µF M 16V ARA OA10801650
C829 N 9965 000 10843 ELECT. 470µF 25V ARS OA47702540
C829 S 9965 000 10843 ELECT. 470µF 25V ARS OA47702540
C829 U 4822 124 11574 ELECT. 1000µF M 16V ARA OA10801650
C830 F 4822 124 11574 ELECT. 1000µF M 16V ARA OA10801650
C830 N 9965 000 10843 ELECT. 470µF 25V ARS OA47702540
C830 S 9965 000 10843 ELECT. 470µF 25V ARS OA47702540
C830 U 4822 124 11574 ELECT. 1000µF M 16V ARA OA10801650
C843 4822 124 22723 ELECT. 1000µF M 25V RA-2 OA10802520
C845 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C851 4822 126 11703 CER. 0.01µF DK98103300
C852 4822 126 11703 CER. 0.01µF DK98103300
C853 4822 126 11703 CER. 0.01µF DK98103300
C854 4822 126 11703 CER. 0.01µF DK98103300
CN01 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CN02 4822 124 40763 ELECT. 2.2µF M 50V RA-2 OA22505020
CN03 4822 124 23649 ELECT. 470µF 25V M RA-2 OA47702520
CN21 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
CN22 4822 124 22273 ELECT. 0.47µF M 50V RA-2 OA47405020
CN23 5322 122 32654 CER. 0.022µF ±10% XTR 16V DK96223200
PH16-RESISTORS
R801 9965 000 06703 CHIP 1.2k ±1% 1/10W NI01122110
R802 9965 000 06703 CHIP 1.2k ±1% 1/10W NI01122110
R804 9965 000 06704 CHIP 2.2k ±1% 1/10W NI01222110
R823 RES. 680 ±5% 1/6W GD05681160
R824 RES. 680 ±5% 1/6W GD05681160
R825 N 9965 000 10842 METAL 1k ±5% 1W NK05102010
R825 S 9965 000 10842 METAL 1k ±5% 1W NK05102010
R826 N 9965 000 10842 METAL 1k ±5% 1W NK05102010
R826 S 9965 000 10842 METAL 1k ±5% 1W NK05102010
RN01 4822 051 30102 CHIP 1k ±5% 1/16W NN05102610
RN02 9965 000 06699 CHIP 3.9M ±5% 1/16W NN05395610
RN03 4822 116 83819 CHIP 18k ±5% 1/16W NN05183610
RN04 4822 117 12925 CHIP 47k ±5% 1/16W NN05473610
RN05 4822 051 30103 CHIP 10k ±5% 1/16W NN05103610
RN06 4822 051 30222 CHIP 2.2k ±5% 1/16W NN05222610
RN07 4822 051 30103 CHIP 10k ±5% 1/16W NN05103610
RN08 4822 051 30472 CHIP 4.7k ±5% 1/16W NN05472610
RN09 4822 051 30472 CHIP 4.7k ±5% 1/16W NN05472610
RN10 4822 051 30223 CHIP 22k ±5% 1/16W NN05223610
RN21 4822 051 30332 CHIP 3.3k ±5% 1/16W NN05332610
RN22 4822 051 30332 CHIP 3.3k ±5% 1/16W NN05332610
RN23 4822 117 13632 CHIP 100k ±5% 1/16W NN05104610
RN24 4822 117 12925 CHIP 47k ±5% 1/16W NN05473610
RN25 4822 051 30333 CHIP 33k ±5% 1/16W NN05333610
RN26 4822 051 30103 CHIP 10k ±5% 1/16W NN05103610
RN27 4822 117 13632 CHIP 100k ±5% 1/16W NN05104610
PH16-SEMICONDUCTORS
D801
9965 000 09763 DIODE SHOTTKY HD20055100
D804 11EQS10 1A 100V
D821
D823 9965 000 09763 DIODE SHOTTKY HD20055100
D824 11EQS10 1A 100V
D825 4822 130 80623 ZENER DIODE 13V HD31301000
D826 4822 130 80623 ZENER DIODE 13V HD31301000
D827 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D828 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D841
9965 000 09763 DIODE SHOTTKY HD20055100
D844 11EQS10 1A 100V
DH01 9965 000 09763 DIODE SHOTTKY
11EQS10 1A 100V
HD20055100
DN01
9965 000 09763 DIODE SHOTTKY HD20055100
DN05 11EQS10 1A 100V
DN06 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DN07 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DN08 4822 130 33948 ZENER DIODE 5.6V HD30561000
DN20 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
Q801 9965 000 06702 IC PQ15RW11 3.0 15V
VARIABLE
HC38915320
Q811 4822 209 73096 IC NJM78M05FA HC38505090
Q812 9965 000 03397 IC BA033FP 3.3V 1A PD=1W HC96J33210
Q821 4822 130 11604 TRS. 2SB1020 HT21020100
Q822 4822 130 11605 TRS. 2SD1415 HT41415100
Q841 4822 209 82828 IC NJM78M12FA HC38512090
QN01 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QN02 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QN03 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QN04 4822 130 61554 CHIP TRS. 2SA1586 Y G HX115862B0
QN05 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
QN20 4822 209 83312 IC TA7317P HC10042050
PH16-MISCELLANEOUS
F801 4822 070 32001 FUSE T2A 250V BS LISTED FS10200850
F821 4822 070 38001 FUSE T800mA 250V
BS LISTED
FS10080850
