Marantz SA12 - Page 158

200
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
F822 4822 070 38001 FUSE T800mA 250V
BS LISTED
FS10080850
F841 4822 070 34001 FUSE T400MA 250V
BS LISTED
FS10040850
FH01 F 4822 070 32001 FUSE T2A 250V BS LISTED FS10200850
FH01 N 9965 000 06705 FUSE T1A H 250V
BUSS MANN S505
FS10100950
FH01 S 9965 000 06705 FUSE T1A H 250V
BUSS MANN S505
FS10100950
FH01 U 4822 070 32001 FUSE T2A 250V BS LISTED FS10200850
GH05 4822 121 43732 FILM CAP. 0.01µF M 250V AC DF77103500
JH01 9965 000 06707 JACK 2P AC INLET M1818-A YJ04002510
JH04 PLUG 4PIN B4P7-VH YP04000930
JH05 4822 265 20359 PLUG CONNECTOR 2P YP04000760
LH02 4822 280 80754 RELAY
VS-12MB.TV-5 UL/CSA/SEMKO
LY10120380
SH02 4822 277 21825 SLIDE SW. SDKGA4 SEMKO SS02021510
PN16-MUTE CIRCUIT BOARD
[ N Only ]
DN92 N 5322 130 11288 CHIP DIODE MA8047-M 4.7V HZ30471000
DN93 N 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
QN91 N 4822 130 61554 CHIP TRS. 2SA1586 Y G HX115862B0
RN92 N 4822 051 30152 CHIP 1.5k
Ω ±5% 1/16W NN05152610
RN93 N 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
PP16-DAC CIRCUIT BOARD
PP16-CAPACITORS
C101 F FILM 1800pF 100V PP APSV OF15182540
C101 N 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C101 S 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C101 U FILM 1800pF 100V PP APSV OF15182540
C102 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C103 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C111 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C111 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C111 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C111 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C112 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C112 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C112 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C112 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C151 F FILM 1800pF 100V PP APSV OF15182540
C151 N 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C151 S 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C151 U FILM 1800pF 100V PP APSV OF15182540
C152 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C153 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C161 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C161 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C161 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C161 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C162 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C162 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C162 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C162 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C201 F FILM 1800pF 100V PP APSV OF15182540
C201 N 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C201 S 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C201 U FILM 1800pF 100V PP APSV OF15182540
C202 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C203 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C211 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C211 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C211 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C211 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C212 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C212 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C212 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C212 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C251 F FILM 1800pF 100V PP APSV OF15182540
C251 N 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C251 S 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C251 U FILM 1800pF 100V PP APSV OF15182540
C252 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C253 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C261 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C261 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C261 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C261 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C262 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C262 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C262 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C262 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C301 F FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C301 N 9965 000 10846 FILM 560pF J 100V NH OF15561550
C301 S 9965 000 10846 FILM 560pF J 100V NH OF15561550
C301 U FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C302 F FILM 150pF ±5% 100V
OFC LEAD APF
OF55151540
C302 N 9965 000 10844 FILM 150pF J 100V NH OF15151550
C302 S 9965 000 10844 FILM 150pF J 100V NH OF15151550
C302 U FILM 150pF ±5% 100V
OFC LEAD APF
OF55151540
C317 F FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C317 N 9965 000 10846 FILM 560pF J 100V NH OF15561550
C317 S 9965 000 10846 FILM 560pF J 100V NH OF15561550
C317 U FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C321 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C321 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C321 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C321 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C322 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C322 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C322 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C322 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C351 F FILM 560pF ±5% 100V
OFC LEAD
OF55561540
C351 N 9965 000 10846 FILM 560pF J 100V NH OF15561550
C351 S 9965 000 10846 FILM 560pF J 100V NH OF15561550
C351 U FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C352 F FILM 150pF ±5% 100V
OFC LEAD APF
OF55151540
C352 N 9965 000 10844 FILM 150pF J 100V NH OF15151550
C352 S 9965 000 10844 FILM 150pF J 100V NH OF15151550
C352 U FILM 150pF ±5% 100V
OFC LEAD APF
OF55151540
C367 F FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C367 N 9965 000 10846 FILM 560pF J 100V NH OF15561550
C367 S 9965 000 10846 FILM 560pF J 100V NH OF15561550
C367 U FILM 560pF ±5% 100V
OFC LEAD APF
OF55561540
C371 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C371 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C371 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C371 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C372 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C372 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C372 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C372 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
